Communication Interface – Product Compatibility List

Some equipment listed in the Compatible Equipment List may not be available for sale or service in certain regions.

機器カテゴリ Equipment Analog
Interface Board
MCO-420MA		 Analog
Interface Board
MTR-420MA		 Interface Board
MTR-MODB1		 LabSVIFT*5
MTR-IOTWE1		 Interface Board
MTR-OPC1
超低温フリーザー MDF-DU503VH/703VH series 　 ✓ ✓ ✓ ✓
MDF-DU503VHE/703VHE series 　 ✓ ✓ ✓ ✓
MDF-DU503VXH/703VXH series 　 ✓ ✓ ✓ ✓
MDF-DU303VXH series 　 ✓ ✓*6 ✓ ✓
MDF-DU302VX/502VX/702VX series 　 ✓ ✓ ✓ ✓
MDF-DU502VH/702VH series 　 ✓ ✓ ✓ ✓
MDF-DU500ZH/700ZH series 　 ✓ ✓ ✓ ✓
MDF-DU500ZHE/700ZHE series 　 ✓ ✓*6 ✓ ✓
MDF-DU901VH series 　 ✓ ✓ ✓ ✓
MDF-DU300H 　 ✓ ✓ ✓ ✓
MDF-U33V/54V/74V series 　 ✓ ✓ ✓ ✓
MDF-C8V1 　 ✓ 　 ✓ 　
MDF-DC200V 　 ✓ 　 ✓ 　
MDF-DC102VH/202VH series 　 ✓ ✓ ✓ ✓
MDF-DC500VX/700VX series 　 ✓ ✓ ✓ ✓
MDF-C2156 series 　 *4 ✓ ✓ ✓
バイオメディカルフリーザー MDF-MU300H/500H series*1 　 ✓ 　 ✓ 　
MDF-MU339/539 series 　 ✓ 　 ✓ 　
MDF-MU339H/539H series 　 ✓ ✓ ✓ ✓
MDF-MU549DH 　 ✓ ✓ ✓ ✓
MDF-U443 　 ✓ 　 ✓ 　
MDF-137/237/437 series 　 ✓ 　 ✓ 　
MDF-U5412 series 　 　 ✓ ✓ ✓
薬用保冷庫 MPR-S1201XH series 　 ✓ ✓ ✓ ✓
MPR-715F 　 ✓ ✓ ✓ ✓
MPR-N250FH series 　 ✓ ✓ ✓ ✓
MPR-N450FH series 　 ✓ ✓ ✓ ✓
MPR-514/1014 series*1 　 ✓ 　 ✓ 　
MPR-S150H/S300H/S500H series 　 ✓ ✓ ✓ ✓
MPR-722/1412 series*1 　 ✓ ✓ ✓ ✓
MPR-N200H series 　 ✓ ✓ ✓ ✓
MPR-N650FH series 　 ✓ ✓ ✓ ✓
血液保冷庫 MBR-305G series 　 　 ✓ ✓ ✓
MBR-705G series 　 　 ✓ ✓ ✓
MBR-1405G series 　 　 ✓ ✓ ✓
CO2インキュベーター MCO-233AIC series *4 　 ✓ ✓ ✓
MCO-173AIC series *4 　 ✓ ✓ ✓
MCO-233AICX series *4 　 ✓ ✓ ✓
MCO-173AICX series *4 　 ✓ ✓ ✓
MCO-50AIC series ✓ 　 ✓ ✓ ✓
MCO-170AIC/230AIC series ✓ 　 ✓ ✓ ✓
MCO-170AC series ✓ 　 ✓ ✓ ✓
MCO-170AICD series ✓ 　 ✓ ✓ ✓
MCO-171AICD series ✓ 　 ✓ ✓ ✓
MCO-80IC series ✓ 　 ✓ ✓ ✓
MCO-5AC series ✓ 　 ✓ ✓ ✓
MCO-18AC series ✓ 　 ✓ ✓ ✓
MCO-20AIC series ✓ 　 ✓ ✓ ✓
マルチガスインキュベーター MCO-50M/170M series ✓ 　 ✓ ✓ ✓
MCO-5M series ✓ 　 ✓ ✓ ✓
冷凍機付きインキュベーター MIR-154*2/254*2/554 series 　 ✓*3 ✓ ✓ ✓
MIR-154S/254S series*1 　 ✓ ✓ ✓ ✓
グロースチャンバー MLR-352 　 *4 ✓ ✓ ✓
MLR-352H 　 *4 ✓ ✓ ✓
バイオハザード対策用キャビネット MHE-S1300 series 　 　 ✓ ✓ ✓
MHE-S901/1301 series 　 　 ✓ ✓ ✓
  1. A separately sold battery mounting box (MPR-48B1) is required to install the communication interface product.
  2. A separately sold harness (MTR-HRNS) is required to install the communication interface product.
  3. Equipment for Japan support analog output as standard. Please refer to the catalog and instruction manual for details.
  4. The equipment supports analog output as standard. Please refer to the catalog and instruction manual for details.
  5. Please contact us regarding service coverage areas.
  6. Please check the firmware (FW) release information page to confirm whether the firmware on your interface board is supported.
